APV® (SPX®) MECHANICAL SEALS

HWS

  • Single or Flushed Seals
  • Suits Rosista W Range
  • Outphased APV® W Pumps

HWS (single) and HWS-F (flushed) are designed to replace the mechanical seals fitted to outphased APV® W or "World" Series centrifugal pumps. Based on Rosista's "W" range prior to acquisition. Not to be confused with newer, W+ range.



HWS & HWS-F share the same inboard o-ring mounted rotary, driven by a legged spring. The HWS stationary is of a monolithic block-type designed to be clamped-in with additional sealing gaskets.

  • Flushed Seal

The HWS-F stationary is double-sided, allowing for an additional external cyclam seal (H) with port hole allowing running of a lubricating fluid.

PARTS

A

B

C

D

E

F

G

H

I

Stationary Gasket

Stationary Face / Ring

Stationary Gasket

Rotary Face / Ring

Rotary Holder

Rotary O-Ring

Rotary Spring

(HWS-F) External Seal

(HWS-F) Ported Seat

EQUIVALENT

T0W / T0WU

Type 16



T0WD / T0WDU

Type 16.DOUB

DATA SHEET

  • Material options

Rotary Face:

Stationary Face:

External Seal:

Gaskets & O-rings:

(CAB) or (SiC)

SiC

CAB/N

EPDM

(_) refers to shrink-fitted

OEM names, brands, model or part numbers are used solely for reference. Our components are engineered to deliver performance and service life equivalent to or exceeding that of OEM parts when correctly installed and appropriately applied. APV® is a registered trademark of its respective company. Pump Seal Supplies Pty Ltd are not representative of, nor affiliated with APV®.

WS - SINGLE & DOUBLE FLUSH SEAL

PRODUCT INFORMATION

PUMP COMPATIBILITY

Replaces the shaft seal in APV "W" range pumps:



Single Seal:

Replaces the OEM part numbers:

179644, 179645, 179650, 179651



Flushed Seal:

Replaces the OEM part numbers:

179656, 179657, 179662, 179663
