EXTERNAL SEALS

HWB2

  • Externally Mounted
  • PTFE Bellows
  • Multi-Spring Pusher
  • Imperial & Metric Sizes
  • Suits Chemicals & Corrosives

HWB2 is a mechanical seal designed to be mounted externally, such that no metal parts are in contact with the process fluid. This makes it ideal for use with highly acidic or chemically corrosive media.



The bellows is extended to allow a two-piece split clamp to tighten and drive the rotary.



The seal is based on the historical "WB2" design, running against industry standard "V" clamped seat. It can also run against many other standardised seats.

  • Operating conditions¹

Temperature:

Pressure:

Speed:

-40°C to +120°C

< 5 bar, 72 psi, 0.5 MPa

< 10m/s, 2000 fpm

rpm < 600000/(79.8 x D1 inch)

rpm < 600000/(3.14 x D1 mm)

PARTS

AB

C

D

E

F

G

H

I

J

K

Stationary PTFE Gasket

Stationary Face / Ring

Stationary PTFE Gasket

Rotary Face / Ring

Rotary PTFE Holder

Rotary PTFE Bellows

Rotary PTFE Cover

Rotary Multi-Springs

Rotary Washer (Bakelite)

Rotary Split Clamp

Rotary Cap Screws

SEAT OPTIONS

V

L

standard

alternative metric

EQUIVALENT

WB2

152



V Seat:

S08 / S08U

Type 25

DATA SHEET

¹Guide-values only (due to diversity of possible applications). Enquire for specific-use cases. Maximum values of each parameter cannot be applied together.

  • Material options

HWB2 - Data Sheet

Rotary Face:

Stationary Face:

Metal Parts:

All Other Parts:

Glass-filled PTFE

SiC or CER

304SS

Virgin PTFE

TYPE WB2

PRODUCT INFORMATION

DIMENSIONS

Dimensions refer to installed length, not 'free' length:
