LOWARA® MECHANICAL SEALS

HU5K

  • O-ring, Conical-Spring Drive
  • To DIN EN 12756 Standards
  • OEM Replacement
  • Lowara e-SV, SV, e-SVI & SVI

HU5K is a DIN EN 12756 L1k compliant

mechanical seal, which replaces the seals fitted to Lowara e-SV and SV - Vertical Multistage pumps as well as e-SVI and SVI - Submersible Vertical Multistage pumps.

PARTS

A

B

C

D

E

F

G

Stationary O-ring

Stationary Face / Ring

Rotary Face / Ring

Rotary O-ring

Rotary O-ring

Rotary Holder

Rotary Spring

EQUIVALENT

  • Material options

Rotary Face:

Stationary Face:

Elastomer:

Metal Parts:

SiC

CAB or SiC

EP or V

304S.S.

T06DU

Type 135

UN5K

DATA SHEET

HU5K - Data Sheet

OEM names, brands, model or part numbers are used solely for reference. Our components are engineered to deliver performance and service life equivalent to or exceeding that of OEM parts when correctly installed and appropriately applied. Lowara® is a registered trademark of its respective company. Pump Seal Supplies Pty Ltd are not representative of, nor affiliated with Lowara®.

UN5K12 / UNK516

PRODUCT INFORMATION

PUMP COMPATIBILITY

Replaces the mechanical seals in Lowara® pumps:



e-SV, SV Range

Replaces the standard mechanical seal: 002231255

Replaces the standard mechanical seal from kit: KL01AAD



Replaces the standard mechanical seal: 002231638

Replaces the standard mechanical seal from kit: KL01AAE



e-SVI Range

Replaces the standard mechanical seal from kit: KL01AH3



Replaces the standard mechanical seal from kit: KL01AH4



SVI Range

Replaces the standard mechanical seal: 002231251

Replaces the standard mechanical seal from kit: KL01AAG



Replaces the standard mechanical seal: 002231657
