CONICAL-SPRING SEALS

HU3

  • O-ring, Conical-Spring Drive
  • Shaft Rotation Dependant
  • To DIN EN 12756 Standards

HU3 is designed to comply with DIN EN 12756, except in fitting length.  It is based on the industry standard "Type 3" design, a conical spring-driven mechanical seal for metric shafts.



The spring provides both axial and rotational force being tightly wound in the direction of the rotating shaft.



Left or right-hand winding springs must be specified.



L1k can be achieved for sizes ≤16mm with a spacer (Sp.). For sizes between 18mm - 32mm a spacer can be used or a longer "3K" spring. For sizes >32mm the "3K" spring is shorter.



An optional "U.C.L." seat is available with an extended tail and anti-rotation pin slot.

  • Operating conditions¹

PARTS

A

B

C

D

E

F

G

H

Stationary O-ring

Stationary Face / Ring

Rotary Seal Ring

Rotary Square-ring

Rotary Frame

Rotary O-ring

Rotary Conical Spring

Spacer (optional)

SEAT OPTIONS

U.C.C.:

U.C.L.:

standard, no slot

extended tail w/ slot

EQUIVALENT

Uniten 3 / 3K

Simplex DIN

Type 13DIN

T04D

BT-FN.NU

43D / P43D

SU3

RB365 / RB365N

RB366 / RB366N

Temperature:

Pressure:

Speed:

-30°C to +200°C

< 10 bar, 145 psi, 1 MPa

< 10m/s, 2000 fpm

rpm < 600000/(3.14 x D1)

¹Guide-values only (due to diversity of possible applications). Enquire for specific-use cases. Maximum values of each parameter cannot be applied together.

DATA SHEET

HU3 - Data Sheet
  • Material options

Rotary Face:

Stationary Face:

Elastomer:

Metal Parts:

CER or SiC

CAB or SiC

N, V or EP

304S.S.

UNITEN 3

PRODUCT INFORMATION

DIMENSIONS

Dimensions refer to installed length, not 'free' length:

Additional sizes >40mm not typically stocked
