SYKES® MECHANICAL SEALS

HSKC-75MM

  • Double Cartridge Seal
  • Replaces OEM: 38-0300-2100
  • Suits Sykes / Primax Pumps

HSKC-75MM replaces the double mechanical cartridge seal assembly "38-0300-2100" used in many Sykes / Primax dewatering pumps.



The seal utilises an internally balanced back-to-back seal face design. Components are housed in an assembly allowing containment of a lubricating fluid.

  • Material Options

Rotary Face:

Stationary Face:

Elastomers:

Metal Parts:

SiC or TC

SiC

V

316SS standard

PARTS

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

Gland Plate - Lower

Stationary O-ring

Stationary Face (x2)

Sleeve Circlip

Sleeve O-ring

Rotary O-ring

Rotary Face / Ring

Sleeve

Stationary Multi-Springs

Stationary O-ring

Setting Clip

Setting Collar

Set Screws

Sleeve Circlip

Gland Plate - O-ring

Gland Plate - Gasket

Gland Plate - Upper

Flush Port

  • Wear Face Kit

EQUIVALENT

HSKC-75MM is available as a face kit, containing only the rotary (G) and stationary (C) seal faces.



Used for repairing existing cartridge units. Requires assembly, not recommended for inexperienced users.

38-0300-2100

DATA SHEET

HSKC-75MM

Data Sheet

OEM names, brands, model or part numbers are used solely for reference. Our components are engineered to deliver performance and service life equivalent to or exceeding that of OEM parts when correctly installed and appropriately applied. Sykes® is a registered trademark of its respective company. Pump Seal Supplies Pty Ltd are not representative of, nor affiliated with Sykes®.

SYKES - 38-0300-2100

PRODUCT INFORMATION

PUMP COMPATIBILITY

Replaces the mechanical seal the following Sykes® pumps:



CP Range (Low Head - "Contractor")

CP300i



HH Range (High Head - "Himax")

HH160



MH Range (Medium Head)

MH300



XH (Extra High Head)

XH80
