CONICAL-SPRING SEALS

HR5

  • O-ring, Conical-Spring Drive
  • Shaft Rotation Dependant
  • Metric Sizes - Italian

HR5 is a conical spring-driven mechanical seal for metric shafts, based on the industry standard "Type 5" design. It is commonly found in heavy-duty pumps of Italian origin.



The spring provides both axial and rotational force being tightly wound in the direction of the rotating shaft.  Left or right-hand winding springs must be specified.



A optional shorter "5H2" spring is available to match working length of HR2, useful when interchanging seals.



An optional "R.C.L." seat is available with an extended tail and anti-rotation pin slot.

PARTS

A

B

C

D

E

F

G

Stationary O-ring

Stationary Face / Ring

Rotary Face / Ring

Rotary O-ring

Rotary O-ring

Rotary Frame

Rotary Conical Spring

SEAT OPTIONS

R.C.C.:

R.C.L.:

standard, no slot

extended tail w/ slot

EQUIVALENT

Type 5 / 5H2

RB305 / RB305N

RB306 / RB306N

DATA SHEET

  • Operating conditions¹

Temperature:

Pressure:

Speed:

-30°C to +200°C

< 10 bar, 145 psi, 1 MPa

< 15m/s, 3000 fpm

rpm < 900000/(3.14 x D1)

HR5 - Data Sheet

¹Guide-values only (due to diversity of possible applications). Enquire for specific-use cases. Maximum values of each parameter cannot be applied together.

  • Material options

Rotary Face:

Stationary Face:

Elastomer:

Metal Parts:

SiC or TC

CAB or SiC

N, V or EP

304S.S.

TYPE 5

PRODUCT INFORMATION

DIMENSIONS

Dimensions refer to installed length, not 'free' length:

Additional sizes not typically stocked, therefore omitted.
