LOWARA® MECHANICAL SEALS

HLCR

  • Refurbishment only
  • Cartridge Seal - Unbalanced
  • To DIN EN 12756 Standards
  • OEM Replacement
  • Suits Lowara e-SVI Pumps

HLCR replaces the unbalanced cartridge seals fitted to Lowara e-SVI

- Submersible Vertical Multistage pumps. The internal component seal is DIN EN 12756 L1k compliant.

  • Material options

Rotary Face:

Stationary Face:

Elastomer:

Metal Parts:

SiC

CAB

V

304S.S.

PARTS

A

B

C

D

E

F

G

H

I

J

K

L

M

Setting Collar

Set Screws

Seal Holder

Seal Holder O-ring

Stationary O-ring

Stationary Face / Ring

Rotary Face / Ring

Rotary O-ring

Rotary Holder O-ring

Rotary Holder

Rotary Spring

Seal Sleeve

Seal Sleeve O-ring

EQUIVALENT

UN5K16 - Cartridge

UN5K20 - Cartridge

DATA SHEET

HLCR - Data Sheet

OEM names, brands, model or part numbers are used solely for reference. Our components are engineered to deliver performance and service life equivalent to or exceeding that of OEM parts when correctly installed and appropriately applied. Lowara® is a registered trademark of its respective company. Pump Seal Supplies Pty Ltd are not representative of, nor affiliated with Lowara®.

UN5K16 / UN5K20 - CARTRIDGE SEAL

PRODUCT INFORMATION

PUMP COMPATIBILITY

Replaces the unbalanced cartridge seals in Lowara® pumps:



e-SVI Range:

Replaces the standard mechanical seal from kit: KL01AH5



Replaces the standard mechanical seal from kit: KL01AH9
