GRUNDFOS® MECHANICAL SEALS

HGSDCR

  • OEM Replacements
  • Suits Grundfos SE, SL Pumps

PARTS

HGSDCR replaces the double mechanical cartridge shaft seal typically fitted to Grundfos SE1, SEV, SL1 and SLV submersible wastewater pumps with motor sizes < 11.0kW.



The cartridge design enables easy service, with the primary & secondary seals assembled in pre-set metal housing that minimises the risk of incorrect fitting.

A

B

C

D

E

F

G

H

I

Secondary Seal Holder

Seal Holder O-ring

Secondary Seal

Setting Clip

Seal Holder

Seal Sleeve

Primary Seal

Shaft O-ring *excluded*

Seal Holder O-ring

DATA SHEET

  • Material options

HGSDCR - Data Sheet

Primary Faces:

Secondary Faces:

Elastomer:

Metal Parts:

SiC/SiC

CAB/CER

V

304S.S.

OEM names, brands, model or part numbers are used solely for reference. Our components are engineered to deliver performance and service life equivalent to or exceeding that of OEM parts when correctly installed and appropriately applied. Grundfos® is a registered trademark of its respective company. Pump Seal Supplies Pty Ltd are not representative of, nor affiliated with Grundfos®.

SUBMERSIBLE PUMP - DOUBLE CART.

PRODUCT INFORMATION

PUMP COMPATIBILITY

Replaces the shaft seal in Grundfos® SE & SL submersible wastewater pumps:



SE1, SEV

Replaces the mechanical seal from OEM:

96102360, 96635732, 96102361, 96635733



SEG

Replaces the mechanical seal from OEM:

96645160, 96645275



SL1, SLV

Replaces the mechanical seal from OEM:

96102360, 99488972, 96102361, 99489003



DP.10.50.26

Replaces the mechanical seal from OEM:

96076123, 76645275
