RUBBER BELLOW SEALS
HGS
- Special rotary length
- Pump-specific
PARTS
HGS is a range of rubber bellows seals with non-standard dimensions specific to individual pumps.
- Operating conditions
A
B
C
D
E
F
Seat Cup
Seat Face
Rotary Face
Rubber Bellows
Spring
L-ring / Collar
Temperature:
Pressure:
Speed:
-20°C to 200°C
up to 12 bar, 175 psi
up to 10m/s, 2000 fpm
DATA SHEET
- Material options
HGS - Data Sheet
Rotary Face:
Stationary Face:
Elastomer:
Metal Parts
CAB, SiC
SiC
V or EP
Stainless Steel
PUMP-SPECIFIC BELLOWS SEAL
PRODUCT INFORMATION
DIMENSIONS
note: dimensions refer to installed length, not 'free' length
