GODWIN® MECHANICAL SEALS

HFC

  • Double Seal, Back-To-Back
  • Semi-Cartridge Design
  • Multi-Spring, O-ring Pusher
  • For Godwin® Dri-Prime® Pumps

HFC replaces the alternative, EagleBurgmann-designed double mechanical seals in Godwin Dri-Prime pump range.

  • Materials

Inboard Faces:

Outboard Faces:

Elastomers:

Metal Parts:

SiC/SiC

SiC/CAB or SiC

V

304SS

  • Wear Face Kit

PARTS

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Inb. Stationary O-ring

Inb. Stationary Face

Inb. Rotary Face

Drive Sleeve

Inb. Rotary O-ring

Inb. Rotary Thrust Ring

Drive Sleeve O-ring

Multi-spring

Set Screws

Drive Collar

Drive Sleeve O-ring

Outb. Rotary Thrust Ring

Outb. Rotary O-ring

Outb. Rotary Face

Outb. Stationary Face

Outb. Stationary O-ring

HFC is also available as a wear face kit, used for repairing existing units. Requires assembly, not recommended for inexperienced users.

DATA SHEET

HFC - Data Sheet

OEM names, brands, model or part numbers are used solely for reference. Our components are engineered to deliver performance and service life equivalent to or exceeding that of OEM parts when correctly installed and appropriately applied. Godwin® Dri-Prime® Xylem® is a registered trademark of its respective company. Pump Seal Supplies Pty Ltd are not representative of, nor affiliated with Godwin® Xylem®.

GODWIN - SEMI-CARTRIDGE

PRODUCT INFORMATION

PUMP COMPATIBILITY

Replaces the mechanical seal in Godwin® pumps:



CD Range

CD160M Mk. 2, CD180M, CD300M (open-coupled versions only)



HL Range

HL130M (earlier versions), HL160M, HL225M, HL250M



OEM Seal Kits

Replaces the mechanical seal only from OEM kits:

SK44/E, SK46/E
