GODWIN® MECHANICAL SEALS

HFB

  • Double Seal, Back-to-Back
  • Wave-spring, O-ring Pusher
  • OEM: Type 3
  • For Godwin® Dri-Prime® Pumps

HFB is equivalent to the "Type 3" heavy duty double mechanical seals in Godwin Dri-Prime pump range.



The seal features two identical rotaries mounted back-to-back.

  • Materials

Inboard Faces:

Outboard Faces:

Elastomers:

Metal Parts:

SiC/SiC

SiC/SiC

V

304SS

PARTS

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Inb. Stationary O-ring

Inb. Stationary Face

Inb. Rotary Face

Inb. Rotary O-ring

Inb. Rotary Holder

Inb. Rotary Drive Collar

Inb. Rotary O-ring

Inb. Rotary Set Screws

Outb. Rotary Set Screws

Outb. Rotary O-ring

Outb. Rotary Drive Collar

Outb. Rotary Holder

Outb. Rotary O-ring

Outb. Rotary Face

Outb. Stationary Face

Outb. Stationary O-ring

EQUIVALENT

Type 1653

DATA SHEET

HFB - Data Sheet

OEM names, brands, model or part numbers are used solely for reference. Our components are engineered to deliver performance and service life equivalent to or exceeding that of OEM parts when correctly installed and appropriately applied. Godwin® Dri-Prime® Xylem® is a registered trademark of its respective company. Pump Seal Supplies Pty Ltd are not representative of, nor affiliated with Godwin® Xylem®.

GODWIN - TYPE 3 - DOUBLE B2B SEAL

PRODUCT INFORMATION

PUMP COMPATIBILITY

Replaces the mechanical seal in Godwin® pumps:



CD Range

CD160M Mk. 1



HL Range

HL110M, HL6M, HL200M



OEM Seal Kits

Replaces the mechanical seal only from OEM kits:

SK43, SK41, GPHL200MSK41



OEM Seal

Replaces the mechanical seal itemised part numbers:

38-1518-9913, 38-0942-4112, 38-1520-9912, 38-1521-9912,

38-1520-9912, 38-1522-9913, 38-1523-9913
