GODWIN® MECHANICAL SEALS

HF

  • Wave-spring, O-ring Pusher
  • OEM: Type 1 - 50mm Seal
  • For Godwin® Dri-Prime® Pumps

HF is equivalent to the 50mm "Type 1" heavy duty single mechanical seals in Godwin Dri-Prime pump range.



The seal features a wave-spring o-ring design and is set-screwed to the shaft. The stationary is of a monolithic clamped-in block-type design.

PARTS

A

B

C

D

E

F

G

H

Stationary O-ring

Stationary Face / Ring

Rotary Face / Ring

Rotary O-ring

Rotary Holder

Rotary Drive Collar

Rotary O-ring

Rotary Set Screws

EQUIVALENT

  • Materials

Type 1725P

Rotary Face:

Stationary Face:

Elastomer:

Metal Parts:

SiC

SiC

V

304SS

DATA SHEET

HF - Data Sheet

OEM names, brands, model or part numbers are used solely for reference. Our components are engineered to deliver performance and service life equivalent to or exceeding that of OEM parts when correctly installed and appropriately applied. Godwin® Dri-Prime® Xylem® is a registered trademark of its respective company. Pump Seal Supplies Pty Ltd are not representative of, nor affiliated with Godwin® Xylem®.

GODWIN - TYPE 1 - 50MM

PRODUCT INFORMATION

PUMP COMPATIBILITY

Replaces the mechanical seal in Godwin® pumps:



CD Range

CD140M, CD225M, CD250M



HL Range

HL100M, HL125M, HL125MS, HL150M, HL150MHD



OEM Seal Kits

Replaces the mechanical seal only from OEM kits:

SK08, SK07, SK40



OEM Seal

Replaces the mechanical seal itemised part numbers:

38-1370-9912, 38-1432-9912, 38-1336-9913, 38-1283-1112
