LOWARA® MECHANICAL SEALS

HE

  • Balanced Seal, O-ring Mounted
  • To DIN EN 12756 Standards
  • OEM Replacement
  • Suits Lowara e-SV, SV & SVI

HE is a DIN EN 12756 compliant balanced mechanical seal, which replaces the seals fitted to Lowara e-SV and SV - Vertical Multistage pumps

as well as SVI - Submersible Vertical

Multistage pumps.



The seal is designed with an internally

housed single spring with torque provided by three drive pins on the

drive ring.

  • Material options

Rotary Face:

Stationary Face:

Elastomer:

Metal Parts:

SiC

CAB

V or EP

304S.S.

PARTS

A

B

C

D

E

F

G

H

I

J

Stationary O-ring

Stationary Face / Ring

Rotary Face / Ring

Rotary O-ring

Rotary Holder

Rotary O-ring

Rotary Spring

Rotary Set Screws

Rotary Drive Ring

Rotary Drive Pin

EQUIVALENT

P0LXB

Type 822

UN8E5K22

DATA SHEET

HE - Data Sheet

OEM names, brands, model or part numbers are used solely for reference. Our components are engineered to deliver performance and service life equivalent to or exceeding that of OEM parts when correctly installed and appropriately applied. Lowara® is a registered trademark of its respective company. Pump Seal Supplies Pty Ltd are not representative of, nor affiliated with Lowara®.

UN8E5K22

PRODUCT INFORMATION

PUMP COMPATIBILITY

Replaces the balanced mech. seals in Lowara® pumps:



e-SV, SV Range

Replaces the standard mechanical seal: 002232300

Replaces the standard mechanical seal from kit: KL01AC0



SVI Range

Replaces the standard mechanical seal: 002232306

Replaces the standard mechanical seal from kit: KL01AC2
