GODWIN® MECHANICAL SEALS

H8B2S

  • Multi-spring, O-ring Pusher
  • Replaces: Type 1 - 40mm Seal
  • For Godwin® Dri-Prime® Pumps

H8B2S is designed to replace the 40mm "Type 1" heavy duty single mechanical seals in Godwin® Dri-Prime® pump range.



The seal features a balanced, multi-spring o-ring design and is set-screwed to the shaft. The stationary is of a monolithic block-type design and is retained by a circlip (not included).

PARTS

A

B

C

D

E

F

G

H

I

Stationary O-ring

Stationary Face / Ring

Rotary Face / Ring

Rotary Snap Ring

Rotary O-ring

Rotary Thrust Ring

Rotary Multi-Springs

Rotary Set Screws

Rotary Holder

EQUIVALENT

  • Materials

Type 1724P

Rotary Face:

Stationary Face:

Elastomer:

SiC

SiC

V

DATA SHEET

H8B2S - Data Sheet

OEM names, brands, model or part numbers are used solely for reference. Our components are engineered to deliver performance and service life equivalent to or exceeding that of OEM parts when correctly installed and appropriately applied. Godwin® Dri-Prime® Xylem® is a registered trademark of its respective company. Pump Seal Supplies Pty Ltd are not representative of, nor affiliated with Godwin® Xylem®.

GODWIN - TYPE 1 - 40MM

PRODUCT INFORMATION

PUMP COMPATIBILITY

Replaces the mechanical seal in Godwin® pumps:



CD Range

CD75, CD80D, CD80M, CD100M, CD103M, CD150M, CD150L, CD200M



HL Range

HL80, HL80M



NC Range

NC80, NC100, NC150



OEM Seal Kits

Replaces the mechanical seal only from OEM kits:

SK14, SK01, SK02, SK03, SK04, SK05, SK42, SK20



OEM Seal

Replaces the mechanical seal itemised part numbers:

38-1445-9912, 38-1446-9912, 38-0620-9913, 38-0700-1112
