JABSCO® (PACKO®) MECHANICAL SEALS

H82/JB55

  • Single Seal Kit, Front-Loaded
  • Suits Jabsco 55 Series

PARTS

H82/JB55 replaces the single mechanical seal face kit fitted to Jabsco 55 Series Ultra-Hygienic Rotary Lobe pumps. Seals face are front-loaded with pre-set fitting lengths, allowing installation without removal of the rotor case.



H82/JB55 includes OEM elastomer "trim kit" and as well as wave spring.



Each pump requires two identical seals, one for each shaft.

A

B

C

D

E

Rotary Cup

Rotary Face / Ring

Stationary Face / Ring

Stationary O-ring

Wave Spring

DATA SHEET

H82/JB55 - Data Sheet
  • Material options

Available in three face material combinations, indicated by the 7th position number in the pump’s code:



Code 3: CAB/SiC

Suitable for most general applications.



Code 2: SiC/SiC

Hard seal faces for abrasive fluids or where shedding of particles into fluid stream must be avoided. Not suitable for CIP steam-purging as seal faces can bind together.



Elastomers: NBR, Viton or EPDM.

  • Double Seal

Parts are also used in double seal configuration. Codes: 1 & 4. Double seal only parts not available.

OEM names, brands, model or part numbers are used solely for reference. Our components are engineered to deliver performance and service life equivalent to or exceeding that of OEM parts when correctly installed and appropriately applied. Jabsco® Packo® is a registered trademark of its respective company. Pump Seal Supplies Pty Ltd are not representative of, nor affiliated with Jabsco® Packo®.

JABSCO - 55 SERIES

PRODUCT INFORMATION

PUMP COMPATIBILITY

Replaces the single mechanical seals in Jabsco 55 Series Rotary Lobe pumps:



Size 2 (20, 21, 22) Range

Nominal Seal Size: 0.700''

OEM Face Kit: SP6080-0528, SP6080-0527

OEM Trim Kit: SP6080-0546, SP6080-0547

Wave Spring: X5250-005



Size 3 (30, 31, 32) Range

Nominal Seal Size: 1.125''

OEM Face Kit: -

OEM Trim Kit: SP2701-1007, SP6080-0549

Wave Spring: -



Size 4 (40, 41, 42) Range

Nominal Seal Size: -

OEM Face Kit: -

OEM Trim Kit: SP6080-0510, SP6080-0511U, SP6080-0551

Wave Spring: -

15/06/2023 - following acquisition by Verder Group, seals are interchangeable with Packo branded 55 Series
