ABS® (SULZER®) MECHANICAL SEALS

H820 / H195P

  • Lower & Upper Tandem Seal
  • Suits ABS® Pumpex® Pumps

PARTS

H820 is an o-ring mounted single spring-driven seal typically replacing the lower position seal in Sulzer® (formerly ABS® / Pumpex®) submersible pump ranges, including "Jumbo", "SP" and "RP" pumps.



H195P is a rubber bellows seal with  an o-ring mounted stationary.



H820 & H195P are specified together and mounted in tandem.

  • Material options

A

B

C

D

E

F

G

H

I

J

K

L

M

N

Lower Rotary Spring

Lower Rotary O-ring

Lower Rotary Holder

Lower Rotary Face / Ring

Lower Stationary Face

Lower Stationary O-ring

Lower Stationary Holder

Upper Rotary "L" Ring

Upper Rotary Bellows

Upper Rotary Spring

Upper Rotary "L" ring

Upper Rotary Face

Upper Stationary Face

Upper Stationary O-ring

EQUIVALENT

Type 820

Type 195P

H820 Seal Faces:

H195P Seal Faces:

Elastomers:

Metal Parts:

SiC/SiC

CAB/S,S

Viton®

304S.S.

DATA SHEET

H820 / H195P

Data Sheet

OEM names, brands, model or part numbers are used solely for reference. Our components are engineered to deliver performance and service life equivalent to or exceeding that of OEM parts when correctly installed and appropriately applied. ABS® Sulzer® is a registered trademark of its respective company. Pump Seal Supplies Pty Ltd are not representative of, nor affiliated with ABS® Sulzer®.

PUMPEX® TANDEM SEAL

PRODUCT INFORMATION

DIMENSIONS

Dimensions refer to installed length, not 'free' length:
