ALFA LAVAL® MECHANICAL SEALS

H82-ALSX

  • R00® - Front-Loading Seal
  • OEM Replacement
  • Suits Alfa Laval® - SX Pumps

H82-ALSX replaces the front-loading "R00®" mechanical seals found in Alfa Laval® SX & SX Ultra Pure Rotary Lobe pumps.



Mechanical seals can be easily replaced by removing the front rotors. Compression distance is pre-set once rotor is reinstalled.



The wave-spring is located behind the rotor alongside a drive ring (excluded).



Each pump requires two identical seals, one for each shaft.

PARTS

A

B

C

D

E

F

G

Rotary Wave Spring

Rotary O-ring

Rotary Face / Ring

Stationary Face / Ring

Stationary O-ring

Stationary Pin

Stationary Holder

EQUIVALENT

R00® Single Seal

DATA SHEET

H82-ALSX - Data Sheet
  • Material options

Rotary Face:

Stationary Face:

Elastomer:

Metal Parts:

CAB

(SiC)

EPDM

316S.S.

(_) refers to shrink fitted

OEM names, brands, model or part numbers are used solely for reference. Our components are engineered to deliver performance and service life equivalent to or exceeding that of OEM parts when correctly installed and appropriately applied. Alfa Laval® is a registered trademark of its respective company. Pump Seal Supplies Pty Ltd are not representative of, nor affiliated with Alfa Laval®.

SX - R00® SEAL

PRODUCT INFORMATION

PUMP COMPATIBILITY

Replaces the mechanical seals in Alfa Laval® pumps:



SX Range:

SX1, SX2, SX3, SX4, SX5, SX6, SX7



SX UltraPure Range:

SX UltraPure 1, SX UltraPure 2, SX UltraPure 3, SX UltraPure 4, SX UltraPure 5, SX UltraPure 6, SX UltraPure 7
