ALFA LAVAL® MECHANICAL SEALS

H82-ALOL

  • EasyFit® - Front-Loading Seal
  • OEM Replacement
  • Suits Alfa Laval® - OptiLobe

H82-ALOL replaces the front-loading "EasyFit®" mechanical seals found in Alfa Laval® OptiLobe Rotary Lobe pumps (formerly SSP Series L)



Mechanical seals can be easily replaced by removing the front rotors. Compression distance is pre-set once rotor is reinstalled.



The wave-spring is located behind the rotor and a drive ring (excluded) provides anti-rotation by locking into the rotor slots.



Each pump requires two identical seals, one for each shaft.

PARTS

A

B

C

D

E

Rotary Wave Spring

Rotary O-ring

Rotary Face / Ring

Stationary Face / Ring

Stationary "L" Cup

EQUIVALENT

EasyFit®

DATA SHEET

H82/ALOL - Data Sheet
  • Material options

Rotary Face:

Stationary Face:

Elastomers:

CAB

316SS

EPDM

OEM names, brands, model or part numbers are used solely for reference. Our components are engineered to deliver performance and service life equivalent to or exceeding that of OEM parts when correctly installed and appropriately applied. Alfa Laval® is a registered trademark of its respective company. Pump Seal Supplies Pty Ltd are not representative of, nor affiliated with Alfa Laval®.

OPTILOBE - EASYFIT® SEAL

PRODUCT INFORMATION

PUMP COMPATIBILITY

Replaces the mechanical seals in Alfa Laval® pumps:



OptiLobe Range:

OptiLobe 12, 13, 22, 23, 32, 33, 42, 43, 52, 53



SSP Series L:

L1-0005,  L1-0010,  L2-0017,  L2-0021,  L3-0032,  L3-0040,

L4-0064,  L4-0082,  L5-0117,  L5-0170
