EXTERNAL SEALS

H8-2

  • Externally Mounted
  • O-ring, Multi-Spring Pusher
  • Pump-specific Sizes
  • Suits Chemicals & Corrosives

H8-2 is a mechanical seal based on the industry standard "Type 8B2". It is designed to be mounted externally, such that no metal parts are in contact with the process fluid. This makes it ideal for use with highly acidic or chemically corrosive media. The rotary may be run against different sized clamped seats specific to each manufacturer.

PARTS

AB

C

D

E

F

G

H

I

J

Stationary PTFE Gasket

Stationary With Flush

Stationary PTFE Gasket

Rotary Face / Ring

Rotary Snap Ring

Rotary O-ring

Rotary Holder

Rotary Thrust Ring

Rotary Multi-Springs

Rotary Set Screws

SEAT OPTIONS

  • Operating conditions¹

Temperature:

Pressure:

Speed:

-40°C to +205°C

< 27 bar, 390 psi, 2.7 MPa

< 23m/s, 4500 fpm

rpm < 1380000/(79.8 x D1 inch)

rpm < 1380000/(3.14 x D1 mm)

Clamped, pump-specific

Fybroc

Armstrong

Bell & Gosset

Sykes

EQUIVALENT

¹Guide-values only (due to diversity of possible applications). Enquire for specific-use cases. Maximum values of each parameter cannot be applied together.

  • Material options

8B2

RA / RA-C

VGXB2

DATA SHEET

H8-2 - Data Sheet

Rotary Face:

Stationary Face:

Elastomer:

Gaskets:

Metal Parts:

CAB or SiC

SiC

N, V or EP

Virgin PTFE

304S.S.

TYPE 8B2

PRODUCT INFORMATION

DIMENSIONS

Dimensions refer to installed length, not 'free' length:

▶ Fybroc Sizes

Complete seals with clamped seats to suit Fybroc pumps:

▶ Other Sizes

Available as rotaries-only:
