EXTERNAL SEALS

H740

  • Externally Mounted
  • PTFE, Multi-Spring Pusher
  • Balanced
  • Metric & Imperial Sizes
  • Suits Chemicals & Corrosives

H740 is a mechanical seal designed to be mounted externally, such that no metal parts are in contact with the process fluid. It is set-screw driven and uses a multi-spring arrangement that ensures even face pressure.



The standard "LG" stationary is equivalent to industry standard "L" seat, designed to be used in "478" gland plates. However, the rotary can also be used to run against many other standardised stationaries.



The seal is supplied with removable setting clips (J) that pre-compress the springs, allowing the set-screws to be tightened to the correct position.

PARTS

1

2

Pump Housing

Gland Plate

AB

C

D

E

F

G

H

I

J

Stationary PTFE Gasket

Stationary Face / Ring

Stationary PTFE Gasket

Rotary Face / Ring

Rotary O-ring

Rotary PTFE Spacer

Rotary Multi-Springs

Rotary Set Screws

Rotary Holder

Rotary Setting Clips

SEAT OPTIONS

LG

standard

EQUIVALENT

740

440

  • Operating conditions¹

DATA SHEET

H740 - Data Sheet

Temperature:

Pressure:

Speed:

-40°C to +200°C

< 10 bar, 150 psi, 1 MPa

< 12m/s, 2400 fpm

rpm < 720000/(3.14 x D1 mm)

rpm < 720000/(79.8 x D1 inch)

¹Guide-values only (due to diversity of possible applications). Enquire for specific-use cases. Maximum values of each parameter cannot be applied together.

  • Material options

Rotary Face:

Stationary Face:

Elastomer:

Metal Parts:

CAB or SiC

CER or SiC

N, V or EP

304S.S. or 316S.S.

TYPE 740

PRODUCT INFORMATION

DIMENSIONS

Dimensions refer to installed length, not 'free' length:
