WATER PUMP SEALS

H68U

  • Unitised Seal
  • One-Piece Cartridge Type
  • Press-Fitted Into Housing
  • Shaft Sealing
  • Suits Automotive Pumps

H68U is a unitised, cartridge-type

version of the H68. The rotating and

stationary assemblies are crimped together during manufacture and supplied as a single, one-piece unit.



The seal has multiple points of sealing. Aside from the sealing faces, leakage is prevented over the shaft as well as the stationary housing bore due to the tight tolerance fit (tool recommended).

  • Operating conditions¹

Temperature:

Pressure:

Speed:

-40°C to +150°C

< 4 bar, 60 psi, 0.4 MPa

< 8m/s, 1560 fpm

rpm < 480000/(3.14 x D1 mm)

rpm < 480000/(79.8 x D1 inch)

¹Guide-values only (due to diversity of possible applications). Enquire for specific-use cases. Maximum values of each parameter cannot be applied together.

PARTS

1

2

Pump Housing

Impeller

A

B

C

D

E

F

G

H

I

Rotary Cup

Rotary Face / Ring

Stationary Face / Ring

Stationary Ferrule

Stationary Bellows

Stationary Spring

Stationary Ferrule

Stationary Metal Head

Stationary Rubber Cup

EQUIVALENT

T6A Unitised

68

Type 75

B

DATA SHEET

H68U - Data Sheet
  • Material options

Standard:

CAB/CER/N

TYPE 6A - UNITISED

PRODUCT INFORMATION

DIMENSIONS

Dimensions refer to installed length, not 'free' length:

▶ H68U - Standard Metric

▶ H68U - Standard Imperial
