WATER PUMP SEALS

H68C

  • Stationary-Based Design
  • Metric & Imperial Sizes
  • Push-Fitted Into Housing
  • Non-Shaft Sealing
  • Suits Automotive Pumps

H68C is a stationary-based seal with

the spring located in the stationary.

An additional rubber cup is fitted over

the H68 base, allowing for an easier

push-fit. This eliminates the need for

any special tools.



Available in two standards. Metric dimensions based on Japanese Automotive industry standard "EH790-TF" design. Imperial dimensions based

on industry standard "Type 6A Cup".

PARTS

1

2

Pump Housing

Impeller

A

B

C

D

E

F

G

H

I

Rotary Cup

Rotary Face / Ring

Stationary Face / Ring

Stationary Ferrule

Stationary Bellows

Stationary Spring

Stationary Ferrule

Stationary Metal Head

Stationary Rubber Cup

EQUIVALENT

  • Operating conditions¹

EH790-TF

EH791-TF

DATA SHEET

H68C - Data Sheet

Temperature:

Pressure:

Speed:

-40°C to +150°C

< 4 bar, 60 psi, 0.4 MPa

< 12m/s, 2400 fpm

rpm < 720000/(3.14 x D1 mm)

rpm < 720000/(79.8 x D1 inch)

¹Guide-values only (due to diversity of possible applications). Enquire for specific-use cases. Maximum values of each parameter cannot be applied together.

  • Material options

Standard:

Optional:

Hard Faces:

CAB/CER/N

CAB/CER/V

SIC/SIC/V

'CUP SEAL'

PRODUCT INFORMATION

DIMENSIONS

Dimensions refer to installed length, not 'free' length:

▶ H68C - Metric Standard

▶ H68C - Imperial Standard

▶ H68C - Alternative Sizes
