METAL BELLOW SEALS

H609

  • Metal Bellows - High Temp.
  • Alloy 42 Low Expansion Holder
  • Imperial Sizes
  • Elastomer-Free

H609 is an edge-welded metal bellows mechanical seal designed to provide resistance to extremely high temperatures e.g. applications involving hot oil transfer. It features a narrow cross-section for better adaptability to suit traditionally narrower seal chambers.

PARTS

A

B

C

D

E

F

G

H

I

J

Stationary Flex. Graphite

Stationary Face / Ring

Rotary Face / Ring

Rotary Face Holder

Rotary Metal Bellows

Rotary Shell

Rotary Flex. Graphite

Rotary Socket Cap Screw

Rotary Set Screws

Rotary Drive Collar

  • Operating conditions¹

SEAT

A

standard, flex. graphite

EQUIVALENT

Temperature:

Pressure:

Speed:

up to +400°C

< 25 bar, 360 psi, 2.5 MPa

< 25m/s, 5000 fpm

rpm < 1500000/(79.8 x D1 inch)

¹Guide-values only (due to diversity of possible applications). Enquire for specific-use cases. Maximum values of each parameter cannot be applied together.

  • Material options

T609

Style 60 / 65

886HT

MFLWT8

BSAIG

DATA SHEET

H609 - Data Sheet

Rotary Face:

Rotary Face Holder:

Metal Bellows:

Secondary Seals:

Shell:

A1, SiC or TC

Alloy 42*

AM350^

Flexible Graphite~

316S.S.

*is an iron-nickel alloy designed for low expansion under high temperatures. Trade name: Carpenter® 42

^is precipitation hardenable stainless steel developed for high strength, excellent weldability along with corrosion

resistance.

~a type of single-use packing which is compressed upon installation. Trade name: Grafoil®

TYPE 609

PRODUCT INFORMATION

DIMENSIONS

Dimensions refer to installed length, not 'free' length:

▶ "X" = 1.27mm
