DIAPHRAGM SEALS
H560DS
- Double seal for stepped shafts
- Pump-specific
- To Japanese specifications
H560DS is the back-to-back arrangement of H560 base to suit stepped shafts. Dimensions are pump-specific, found commonly in Japanese-brand submersible pumps. H560DS uses a unique non-driving conical spring.
CODE
•
TS
SK
EB
PD
◊
standard
Tsurumi
Sakuragawa
Ebara
Saer PD
misc.
PARTS
- Operating conditions
Temperature:
Pressure:
Speed:
-30°C to 200°C
up to 10 bar, 145 psi
up to 13m/s, 2500 fpm
- Material options
External:
Internal:
Elastomer:
Metal Parts
CAB/CER, SiC/SiC
SiC/SiC
N, V
Stainless Steel
A
B
C
D
E
F
G
H
Seat Cup
Seat
Rotary Face
Retainer
Rubber Diaphragm
Spring
Drive Band
Locking Washer
DATA SHEET
H560DS - Data Sheet
TYPE 560DS - STEPPED SHAFT
PRODUCT INFORMATION
DIMENSIONS
note: dimensions refer to installed length, not 'free' length
