DIAPHRAGM SEALS

H560D

  • Diaphragm w/ Drive Band
  • Double Seal
  • To Japanese Specifications

H560D is a double mechanical seal in a back-to back arrangement. It is  widely used to seal the oil chamber in submersible pumps of Japanese origin.



The rotary retainer is crimped to prevent movement of the face and rubber diaphragm.



The inboard stationary is vulcanised (bonded) by the elastomer and held in place by a retainer plate (optional).

PARTS

A

B

C

D

E

F

G

H

I

J

K

L

M

N

Inb. Vulcanised Rubber

Inb. Stationary Face

Retaining Plate (optional)

Inb. Rotary Face

Inb. Rotary Retainer

Inb. Rotary Diaphragm

Inb. Rotary Drive Collar

Spring

Outb. Rotary Drive Collar

Outb. Rotary Diaphragm

Outb. Rotary Retainer

Outb. Rotary Face

Outb. Stationary Face

Outb. Stationary Cup

  • Operating conditions¹

EQUIVALENT

Temperature:

Pressure:

Speed:

-30°C to +200°C

< 10 bar, 145 psi, 1 MPa

< 13m/s, 2500 fpm

rpm < 780000/(3.14 x D1)

¹Guide-values only (due to diversity of possible applications). Enquire for specific-use cases. Maximum values of each parameter cannot be applied together.

ED560 (Ver. A)

VGM562

Type 260B

RB562

PBV

S560D

  • Material options

DATA SHEET

Inboard:

Outboard:

Elastomer:

Metal Parts:

SiC/SiC

CAB/SiC or SiC/SiC

N or V

304S.S.

H560D - Data Sheet

Special "H560D/X" Versions:

H560D/X

Data Sheet

TYPE 560D

PRODUCT INFORMATION

DIMENSIONS

Dimensions refer to installed length, not 'free' length:

▶ H560D - Standard

VM - Inboard Seat (Vulcanised), JCD - Outboard Seat (Cup)

* and Ver. B non-standard ED560    ^JCD Seat Inboard

▶ H560D - Special Versions

Ver. L = Lipped seats, Ver. C / D = Cup, Ver. V = VM seat Inb./Outb.
