WATER PUMP SEALS
H55
- Enclosed rubber bellows
- Compact
- Suits common water pumps
H55 is designed to replace the mechanical seals in mass-produced cold water pumps and owes its success to its compact, enclosed rubber bellows design with a wide stationary seat. The seal is commonly referred to as "Cyclam" seals.
PARTS
A
B
C
D
E
F
Seat Cup
Stationary Face
Rotary Face
Metal Collar
Rubber Bellows
Spring
EQUIVALENT
- Operating conditions
Temperature:
Pressure:
Speed:
-30°C to 200°C
87 psig / 6 bar g
up to 12m/s, 2400 fpm
- Material options
Rotary Face:
Stationary Face:
Elastomer:
Metal Parts
CAB, SiC
CER, SiC
N, V
S.S.
T55
PR / DR
BT-AR
B01
Type 18
P118
FA
T750
37B / L5
BT
301
DATA SHEET
H55 - Data Sheet
(updated 2023)
CYCLAM SEAL, EURO SEAL
PRODUCT INFORMATION
DIMENSIONS
D1 = Shaft Size
D3 = Rotary O.D.
L1 = Rotary Working Length
D7 = Bore / Cavity
L4 = Seat Thick.
