SYKES® MECHANICAL SEALS

H502/S

  • Rubber Bellows Drive
  • Replaces OEM: 726350
  • Suits Sykes / Primax Pumps

H502/S replaces the OEM 50mm: "726350" seal assembly found in many Sykes / Primax dewatering pumps.



The seal is rubber bellows driven which extends the full length of the seal, protecting the shaft against wear. The internal components are encased and protected by a metal housing. The stationary is of a monolithic block-type design and is slotted to engage with a pin in the seal housing for anti-rotation.

  • Materials

PARTS

A

B

C

D

E

F

G

H

I

Stationary O-ring

Stationary Face / Ring

Rotary Face / Ring

Rotary Washer

Rotary Washer

Rotary Metal Housing

Rotary Spring

Rotary Rubber Bellows

Rotary Drive Collar

EQUIVALENT

726350

38-0814-BJ1S1/D

2-8-0500-VS2SS2/SS

Rotary Face:

Stationary Face:

Elastomers:

Metal Parts:

SiC

SiC

V

304SS

DATA SHEET

H502/S - Data Sheet

OEM names, brands, model or part numbers are used solely for reference. Our components are engineered to deliver performance and service life equivalent to or exceeding that of OEM parts when correctly installed and appropriately applied. Sykes® is a registered trademark of its respective company. Pump Seal Supplies Pty Ltd are not representative of, nor affiliated with Sykes®.

SYKES - 726350

PRODUCT INFORMATION

PUMP COMPATIBILITY

Replaces the mechanical seal the following Sykes® pumps:



CP Range (Low Head - "Contractor")

CP250



HD Range

HD250, HDHH130, HDMH130, HDMH150



HH Range (High Head - "Himax")

HH130



MH Range (Medium Head)

MH130, MH150
