RUBBER BELLOW SEALS

H502

  • Rubber Bellows Drive
  • To DIN EN 12756 Standards
  • High Pressure
  • Non-Clogging, Self-Aligning
  • Bi-Directional

H502 is a DIN EN 12756 compliant

mechanical seal for metric shafts,

based on the industry standard "Type

502" design. It is widely specified as

a "high-pressure" alternative for existing seal configurations without impacting fitted working lengths.



The rubber bellows extends the full

length of the seal, protecting the shaft against wear. The bellows and spring are encased by a metal housing protecting these components from impact damage.



An optional "BP" seat includes an extended tail with a slot to accommodate an anti-rotation pin

  • Operating conditions¹

PARTS

A

B

C

D

E

F

G

H

I

Stationary O-ring

Stationary Face / Ring

Rotary Face / Ring

Rotary Washer

Rotary Washer

Rotary Metal Housing

Rotary Spring

Rotary Rubber Bellows

Rotary Drive Collar

SEAT OPTIONS

BO

BP

BM

standard

w/ anti-rotation slot

cup-mounted

EQUIVALENT

T502

B07 / B07S / B07SL

Type 1724S / 1724L

250 / P250

RB852

Temperature:

Pressure:

Speed:

-40°C to +205°C

< 40 bar, 580 psi, 4 MPa

< 13m/s, 2500 fpm

rpm < 780000/(3.14 x D1)

¹Guide-values only (due to diversity of possible applications). Enquire for specific-use cases. Maximum values of each parameter cannot be applied together.

DATA SHEET

H502 - Data Sheet
  • Material options

Rotary Face:

Stationary Face:

Elastomer:

Metal Parts:

CAB, SiC or TC

CER, SiC or TC

N, V or EP

304S.S.

TYPE 502

PRODUCT INFORMATION

DIMENSIONS

Dimensions refer to installed length, not 'free' length:
