WATER PUMP SEALS

H16

  • Compact Rubber Bellows
  • To Imperial Dimensions
  • Suits Pool & Water Pumps

H16 is a compact elastomer bellows

mechanical seal, based on the industry standard "Type 6" design. It is commonly used in general purpose

small diameter pool & water pumps.

  • Operating conditions¹

Temperature:

Pressure:

Speed:

-45°C to +205°C

< 5 bar, 75 psi, 0.5 MPa

< 5m/s, 1000 fpm

rpm < 300000/(79.8 x D1)

¹Guide-values only (due to diversity of possible applications). Enquire for specific-use cases. Maximum values of each parameter cannot be applied together.

  • Material options

Standard:

Hard Faces:

CAB/CER/N

SiC/SiC/V

  • Alternative "H303" Rotary

An alternative "H303" design is  available which features a hex-torque metallic drive & crimped head.

PARTS

A

B

C

D

E

F

G

H

I

Stationary Cup

Stationary Face / Ring

Rotary Face / Ring

Rotary Drive Sleeve

Rotary Bellows

Rotary Ferrule

Rotary Spring

Rotary Ferrule

Rotary Rubber Ring

EQUIVALENT

T6

16

EA106

Type 60

B04 / B04U

160 / P160 / P161

Type 60L / Type 65

RB860

DIS. B



PAC 16 (H303)

BT-PNT (H303)

DATA SHEET

TYPE 6

PRODUCT INFORMATION

DIMENSIONS

Dimensions refer to installed length, not 'free' length:

▶ H16 - Standard

▶ H303 - Standard
