CONICAL-SPRING SEALS
H12N
- Conical / tapered spring
- Balanced
- Dependent on direction of rotation
- DIN 24960 Cavities
H12N is the balanced version of the H32 / H37 seal
PARTS
A
B
C
D
E
F
O-ring
Seat (G9 standard)
Rotary Face Insert
Housing
O-ring
Conical Spring
- Operating conditions
Temperature:
Pressure:
Speed:
-30°C to 260°C
up to 25 bar, 360 psi
up to 15m/s, 3000 fpm
EQUIVALENT
H12N
- Material options
STANDARD SEAT
Rotary Face:
Stationary Face:
Elastomer:
Metal Parts
CAB, SiC, A1. CAB
SiC
N, V or EP
Stainless Steel
G9
DIN metric slotted seat
DATA SHEET
H12N - Data Sheet
TYPE H12N
PRODUCT INFORMATION
DIMENSIONS
note: dimensions refer to installed length, not 'free' length
