ALFA LAVAL® MECHANICAL SEALS

ALC-SS

  • ALC - "D"-Type Single Seal
  • OEM Replacement
  • Suits Alfa Laval® - ALC Pumps

ALC-SS is a replacement for the "D" - Type single mechanical seals found in Alfa Laval® ALC centrifugal pumps.



The stationary is o-ring mounted and slotted to align with anti-rotation pin in the pump housing.

PARTS

A

B

C

D

E

F

G

Stationary O-ring

Stationary Face / Ring

Rotary Face / Ring

Rotary "L" Ring

Rotary Rubber Bellows

Rotary Spring

Rotary "L" Ring

EQUIVALENT

  • Material options

Rotary Face:

Stationary Face:

Elastomer:

Metal Parts:

CAB or SiC

SiC

EP or V

304SS

B09DU

Type 19C

DATA SHEET

ALC-SS - Data Sheet

OEM names, brands, model or part numbers are used solely for reference. Our components are engineered to deliver performance and service life equivalent to or exceeding that of OEM parts when correctly installed and appropriately applied. Alfa Laval® is a registered trademark of its respective company. Pump Seal Supplies Pty Ltd are not representative of, nor affiliated with Alfa Laval®.

ALC - "D"-TYPE SINGLE SEAL

PRODUCT INFORMATION

PUMP COMPATIBILITY

Replaces the single mech. seals in Alfa Laval® pumps:



ALC Range:

ALC-1, ALC-2, ALC-3
